RUBBER TILES


A | B | C | D | E | F | G | H | I | J | K | L | M | N | O | P | Q | R | S | T | U | V | W | X | Y | Z

AFCO TACTILEŽ  Warning Strip  (CT-1820)
Tactile Warning Strip meet ADA specifications for interior installations to warn visually impaired persons of potential hazards, such as ramps, curbs, or stairs. Non-skid rubber strips are made 1/8" thick (grooved rubber)

SPECIFICATIONS
Widths:
9", 12", 18", 24", 36"
Lengths: 36", 42", 48", 54", 60", 72"
Colors: (602)Arizona Sunset, (604)Black Marble, (608)Ebony, (627)Fossil, (630)Mahogany Swirl, (702)Milck Chocolate, (711)Dove Gray, (766)Slate Gray, (777)Marbleized Fawn, (785)French Vanilla.

Cross Section

CT-1820

Back to the top


AMERICAN BEAUTYŽ  Sheet Rubber Flooring  (AT-704)
AMERICAN BEAUTYŽ  Tile  (AT-715)

The American Beauty line of flooring and tiles are resilient, quiet and long wearing.

SPECIFICATIONS (C.S.I. Div. 9 Flooring)
Flooring and tiles shall be made of top quality rubber, homogeneous colors, and free of blemishes. Flooring shall be delivered in rolls of up to approximately 17 to 30 yards in length. Flooring shall be supplied with unfinished edges for double-cut installation. The back side shall be sanded to provide secure adhesion.
Flooring and Tile Thickness: 1/8"
Full Roll Size: up to approx. 17-30 yards.
Flooring Width: 36"
Tile Size: 12" x 12"

AT-715

Colors for: AT-704 & AT-715
Select Colors

Back to the top


ARIZONA-MESAŽ  Tile  (ES-737)
Arizona-MesaŽ tiles have a hammered surface look, made with either solid or speckled desert colors.

SPECIFICATIONS
Thickness:
9/64" (3.5 mm)
Sizes/Weight: 17-13/16" x 17-13/16" (2.62 lbs./tile)
                      35-11/16" x 35-11/16" (10.5 lbs./tile)
Colors: (101)Granite Falls, (103)Silver Circle, (111)Emerald Isle, (117)Whimsical White, (130)Maltese Gray, (133)Polished Pewter, (134)Platinum Gray, (14)Egyptian Shadow, (142)Almond Biscotti, (144)Roycroft Tan, (145)Casa Madrona, (146)Buckskin, (150)Sienna Sunset, (155)Alfresco Brick, (157)Copper Dust, (173)Golden Valley, (180)Aqua Teal, (181)Green Mint, (183)Lime Sorbet, (190)Blue Willow, (191)Night Sky.
Fire Rating: Class 1
Smoke Generation Value: Less than 0.450

WARRANTY: ES FLOORING group is guaranteed against premature wear and manufacturing defects on a five year pro-rata limited warranty.

INSTALLATION
Use ES Polyurethane Adhesive to install above grade. The sub floor must be dry, clean and smooth. Expansive joints, cracks, grooves or other irregularities shall be leveled or filled with a good quality underlayment. It is the responsibility of the flooring contractor to determine the suitability of the sub floor. When the area is on or below grade, Epoxy Adhesive is essential.

Back to the top


BRIGADIER IIŽ  Tile  (AT-710)
Solid color, molded tiles shall be made of top quality rubber compound, homogeneous colors, heat cured and free of blemishes. Diamond design surface.

SPECIFICATIONS (C.S.I. Div. 9 Stair Treads)
Thickness:
7/32"
Size: 24" x 24"
Carton: 10 Tiles.
Solid Colors: (107)Dk. Brown, (108)Black, (111)Lt. Gray, (127)Med. Brown, (142)Dk. Blue, (146)Med. Gray, (165)Burgundy, (166)Slate, (177)Beige, (183)Dk. Green.

AT-710

INSTALLATION
Fallow the arrows on back side of each tile to assure proper tile alignment. Use Armor Contact Adhesive (AD-1303) or 2 part Polyurethane Adhesive (AD-1390)

Back to the top


METROTILE®   (ES-747)
MetrotileŽ's 1" x 1" repeating pattern of squares has a raised height of only 0.6 mm above the base.

SPECIFICATIONS
Thickness: 1/8"
Size: 24" x 24"
Weights: 44 lbs.
Marbleized or Solid Colors: (01)Snow White, (05)Stone, (09)Clay, (11)Canvas, (12)Hard Rock, (15)Cabernet, (18)Navy Blue, (20)Charcoal, (21)Platinum, (22)Pearl, (24)Gray Haze, (27)Mist, (28)Medium Gray, (29)Moon Rock, (30)Ink, (31)Zephyr, (32)Pebble, (33)Adobe Peach, (34)Almond, (38)Pewter, (40)Black, (41)Sea Breeze, (42)Sable, (43)Hyacinth, (45)Sandalwood, (47)Brown, (48)Gray, (49)Beige, (55)Silver Gray, (58)Windsor Blue, (59)Heather Green, (60)Taupe,

ES-747

(62)Tangerine Tango, (63)Burnt Umber, (64)Keylime, (70)Bluest,  (71)Storm Cloud, (72)Harbour, (73)Palm Leaf, (74)Iris, (75)Lemon, (76)Cinnamon, (80)Fawn, (84)Blue Jeans, (85)Burgundy, (86)Hunter Green, (92)Blue Lagoon, (101)Seaweed, (121)Cement, (125)Blush, (128)Lavender, (129)Silk, (130)Sisal, (132)Espresso, (134)Gold Rush, (140)Carrot, (141)Lipstick, (142)Aquatic, (143)Marine, (144)Blueprint, (148)Paprika, (150)Wetlands, (151)Iguana, (152)Shamrock, (162)Sovereign, (163)Salsa, (164)Smolder, (165)Squashed, (166)Sienna, (168)Thunder, (185)Dreamsicle, (187)Pansy, (190)Greege, (192)Tidewater.

Select Colors

Back to the top


MONTANA-SLATE® Tile  (ES-744)
Montana-SlateŽ tiles have an embossed slate surface design, made with either solid or speckled dessert colors.

SPECIFICATIONS
Thickness: 9/64" (3.5 mm)
Sizes/Weights: 17-13/16" x 17-13/16" (2.62 lbs./tile)
                        35-11/16" x 35-11/16" (10.5 lbs./tile)
Solid Colors: (123)Midnight Charcoal, (133)Polished Pewter, (137)Carriage Gray, (189)Emerald Luster, (191)Night Sky.
Speckled Colors: Same as ARIZONA-MESAŽ TILE above.
Fire Rating:
Class 1
Smoke Generation Value: Less than 0.450

WARRANTY: ES FLOORING group is guaranteed against premature wear and manufacturing defects on a five year pro-rata limited warranty.

Select Colors

Back to the top


ORBITILE®  (ES-717)
The OrbitileŽ has a continuous pattern of quarter size discs raised only 1 mm above the background.

SPECIFICATIONS
Thickness: 9/64" (3.5 mm)
Sizes/Weights: 17-13/16" x 17-13/16" (2.62 lbs./tile)
                        35-11/16" x 35-11/16" (10.5 lbs./tile)
Colors: (120)Onyx Black, (123)Midnight Charcoal, (133)Polished Pewter, (134)Platinum Gray, (137)Carriage Gray, (140)Sandstone Beige, (148)Deep Chestnut, (150)Sienna Sunset, (152)Cherry Red, (155)Alfresco Brick, (173)Golden Valley, (180)Aqua Teal, (181)Green Mint, (183)Lime Sorbet, (190)Blue Willow, (191)Night Sky.

ES-717

Select Colors

Back to the top
